Bristle Lasting Belts technology simultaneously removes corrosion and generates anchor profile.
The bristle tips are designed to strike the corroded surface with kinetic energy that is equivalent to standard processes that use grit blast media.
|
Product Details:
Payment & Shipping Terms:
|
Item Name: | Bristle Laster Belts 23mm | OD: | 102mm |
---|---|---|---|
ID: | 51.5 | Wire Material: | HSS Wire |
Wire Dia: | 0.7mm | Face Width: | 23mm |
23mm Width Carbon Steel Bristle Laster Belt 110mm OD for MonIti or Mbx Machine
Bristle Lasting Belts technology simultaneously removes corrosion and generates anchor profile.
The bristle tips are designed to strike the corroded surface with kinetic energy that is equivalent to standard processes that use grit blast media.
Immediately after the bristle tips strike the surface, they retract (“rebound”) from the surface, which results in both corrosion removal and micro-indentation that exposes fresh surface.
Consequently, surfaces that have been treated by Bristle Blasting Belts have a texture and visual cleanliness that mimics those obtained by traditional grit blasting processes.
Removes corrosion, coatings, mill scale and other contaminants – without removing healthy material
Generates anchor profiles ranging from 2,5 to 3,3mil also on weld seams, edges, around bolts and on surface irregularities
Restores corroded and pitted surfaces to near-white metal or white metal appearance – no grinding or polishing
Generates compressive residual stress for crack growth resistance, improved life and improved corrosion resistance
Cleans and profiles with long lasting, safe Bristle Blaster Belts – eliminating the need for costly abrasive blast equipment
Bristle Laster Belts consist of a high performance polyamide fabric. The U-shaped bristles made of carbon spring steel or of stainless steel are anchored in the belt. The Bristle Blaster belts are highly flexible which ensures a high level of safety and a long service life.
Outer diameter: 102mm or 110mm
Bristle Laster Belt 23 mm (carbon spring steel) – 0.7 mm carbon spring steel wire, tips angled and sharpened.
Bristle Laster Belt 11 mm (carbon spring steel) – 0.7 mm carbon spring steel wire, tips angled and sharpened. Designed for difficult to reach areas (90° angles, fillet welds).
Bristle Laster Belt 23 mm (stainless steel) – 0.7 mm stainless steel wire, tips angled and sharpened.
Bristle Laster Belt 11 mm (stainless steel) – 0.7 mm stainless steel wire, tips angled and sharpened. Designed for difficult to reach areas (90° angles, fillet welds).
1. Reduces surface preparation time by 75%
2. Creates a ‘blasted surface’ for superior adhesion
3. Unique on & off accelerator bar is an option
Outer diameter | 102mm |
---|---|
Inner hole Diameter | 51.5 mm |
Wire material & Wire Dia. | 0.7mm HSS Wire |
Saves time and money vs. traditional methods
