Maximum Fill Density Turbo Line 150mm Silicon Carbide Disc Deburring Brushes
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Item Name: | Disc Deburring Brushes | OD: | 150MM |
|---|---|---|---|
| Shank Dia.: | 25.4MM | Bristle Trim Length: | 25mm |
| Base Thickness: | 20mm | Base Color: | Green |
| Bristle Dia: | 1.1mm | Grits: | 120 |
Professional Maximum Fill Density Turbo Line 150mm Silicon Carbide Disc Deburring Brushes
Combination Filament, 150mm Diameter, 0.04" Wire Diameter, 25.4mm inner diameter, 20mm Bristle Length
Product Features
With a unique, and infinitely variable manufacturing process, our factory can design and manufacture an abrasive, or non-abrasive, filament brush for your specific application.
Producing a brush for a specific application, or often a specific part, ensures that our customers are always using the most cost effective product.
Most brushes are also available with Silicon Carbide, Ceramic, Aluminum Oxide or Diamond abrasive filaments
Product Description
These disc brushes are manufactured with a molded thermoplastic base using a tough engineering plastic to provide more rigidity and stability with less vibration. Our unique combination of silicon carbide and ceramic filaments are used to allow the brushes to cut faster and last longer than any other brush on the market.
Product Dimensions:
Both brush styles are available in three different diameters: 100 mm, 125 mm 150mm and 200 mm to suite a range of parts and finishing machinery.
The brushes are available in 18-mm or 38-mm trim lengths to provide the perfect combination of flexibility and aggressiveness.
Shorter trim lengths result in more aggressive cutting where heavy burrs are present and longer trim lengths allow irregular surfaces to be finished easily.
Custom sizes and shapes possible.
|
Outer Diameter
|
150mm |
|
Inner Diameter
|
25.4mm |
|
Base thickness
|
20MM |
|
Bristle height
|
25mm |
|
Bristle Dia.
|
1.0mm |
Applications:
• Ideal for deburring any flat machined auto parts
• Deburring face milled casting and forgings
• Edge blending and edge radiusing operations
• Fine blank deburring
• Engine block and cylinder head deburring
• Surface finish and removing burrs on hydraulic components
• Rust and scale removal
• Clean pre-cast concrete moulds
• Sanding and texturing wood surfaces
• Surface conditioning alloy wheels
