Custom 25mm Aluminum Oxide Flexible Cylinder Honing Tool Brush for Surface Finishing
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Item: | Cylinder Honing Tool Brush | OD: | 25MM |
|---|---|---|---|
| Bristle Length: | 70mm | Total Length: | 200mm |
| Grits: | 240 Grits | Material: | Aluminum Oxide |
Custom 25mm Aluminum Oxide Flexible Cylinder Honing Tool Brush for Surface Finishing
Product Description
The flexible nylon provides the right pressure to create an ideal plover hole
Automatic centering and automatic calibrate the hole surface for fine consistent machining ,
the original accuracy and dimension of the work piece are not affected
Reduce Ra, reach in to a smooth surface finish,undeformed and has an ideal edge break through.
Flexible hone, Flexible Ball Style Hone For Surface Finishing & Deburring.
Fill Material: Silicon Carbide & Aluminum Oxide,Grit:#60,#120,#180,#240,#320,#600...
Key Features:
1. Sturdy, self-centering stem.
2. Flexible filaments are engineered to provide the correct pressure to create an ideal hone - bore after bore.
3. Rigid abrasive media is firmly attached to the end of the flexible filaments making the tool excellent for tough cross-hole deburring and edge radiusing applications.
4. Fill Material:Silicon Carbide or Aluminum Oxide,different grit choice,such as 60,120,180,240,320,600,800,1000…
Product Size:
1. Brush diameters ranging from 5mm to 280mm,Round brush diameter is 64mm & 76mm.
2. Brush length ranging from 50mm to 180mm.
3. Stem diameters ranging from 1.8mm to 10mm.
4. Overall length is from 150 to 500mm.
5. Flexible ball style hone for surface deburring & finishing of cylinder bores,oil and gas pipe,nuclear water pipe,metal (stainless steel,iron,aluminium) tubing, Forcing cone hones.
6. A compliant honing tool for brushing cylindrical surfaces.
Applications:
1. Honing
2. Creating cross hatched surface pattern for oil retention
3. Cylinder port area deburring
4. Eliminating inside flashing
Product Description
Enter place where normal tools are difficult to access , such as cracks and grooves
Removing burr , sharp edge becoming obtusely smooth and even arcs , so as to achieve the ideal effect of de burring ,cutting edge passivation and surface finishing
-
A/O,S/C & diamond honing stones,Cross-hole deburring tool;
-
Standard-duty & heavy-duty silicon carbide flexible hone;
-
Flexible ball style hone for surface deburring & finishing of cylinder bores,oil and gas pipe,nuclear water pipe,metal (stainless steel,iron,aluminium) tubing, Forcing cone hones.
-
Air Compressors Bores • Compressed Air Tool Bodies • Hydraulic Ram Cylinders • Brake Cylinders (Wheel)
-
Flexible ball style hone for surface deburring & finishing of cylinder bores,oil and gas pipe,nuclear water pipe,metal (stainless steel,iron,aluminium) tubing, Forcing cone hones.
-
-
Outer diameter
25mm total length
200cm bristle length
70cm bristle material
Aluminum Oxide Grits
240 -
-
NOTE: if you don't know your need brush size .pls contact our customer service to consult. davis at chinawirebrush dot com
-
