10 Inch Diameter Hard Alloy CBN Tool Edge Passivation Abrasive Wire Roller Brush with Hex Hole
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Item Name: | Abrasive Wire Roller Brush With Hex Hole | OD: | 250mm |
|---|---|---|---|
| Inner Hole: | 50.8 Mm | Wire Material: | Du-pond Abrasive Nylon |
| Face Length: | 300mm | Grits: | 1000 |
| Bristle Dia: | Grey |
10 Inch Diameter Hard Alloy CBN Tool Edge Passivation Abrasive Wire Roller Brush with Hex Hole
This industrial brush is a specialized tool designed for edge preparation, deburring, and passivation of hard materials, particularly hard alloys like tungsten carbide, high-speed steels, and superalloys.
Features:
- Adopt high density abrasive wire, acid and alkali resistant, anti-corrosion, not easy to break.
- Can be installed to drawing machine for Tool Edge Passivation.
- Suitable for kinds of surface, such as flat, curved, concave, convex or irregular surface.
- 120# grit for fine polishing effect.
- High quality product for long durability and high efficient performance.
Good understanding of production processes enables rapid development of efficient solutions and various alternatives can be presented.
Through a high level of flexibility in working methods, various requirements can all be met while development projects are ongoing. When new ideas are generated
Description:
Technical Specifications
- Outer Diameter: 10 inches (approx. 254 mm). Provides a large contact area and long tool life, ideal for automated machinery.
- Abrasive Material: CBN (Cubic Boron Nitride). CBN is the second-hardest known material after diamond. It features high thermal stability and chemical resistance, making it perfect for ferrous metals and hard alloys where diamond would chemically react.
- Core / Mounting: Hexagonal Center Hole. The hex bore ensures positive drive engagement, preventing the brush from slipping on the machine's drive shaft under high torque.
- Filament Type: Abrasive Wire (Nylon or polymer extruded with encapsulated CBN grit).
10" Abrasive Wire Brush Roller, diameter. 1000 Grit. 2" Arbor hole. 300mm total length
| Outer diameter | 300mm |
|---|---|
| Inner hole | 50.8mm |
| Wire material & Wire Dia. | 1000 grits |
Key Benefits of CBN Abrasive Wire
- Exceptional Thermal Stability: Unlike diamond, which degrades when grinding iron-based metals at high temperatures, CBN maintains its hardness and cutting efficiency up to 1,000°C.
- Consistent Performance: The abrasive grit is embedded throughout the flexible nylon filament. As the wire wears down, new CBN particles are exposed, ensuring uniform edge radiusing over time.
- Flexible Contact: The wire filament conforms to complex tool geometries, allowing it to hone cutting edges uniformly without altering the overall macro-geometry of the workpiece.
- No Slippage: The hex hole design handles high rotational loads effortlessly, making it highly reliable for automated CNC edge preparation lines
